Application

• Linearized temperature measurement with Pt100...Pt1000 or Ni100...Ni1000 sensor.
• Conversion of linear resistance variation to a standard analog current signal, for instance from valves or Ohmic level sensors.

Technical characteristics

• Within a few seconds the user can program PR6333A to measure temperatures within all RTD ranges defined by the norms.
• The RTD and resistance inputs have cable compensation for 3-wire connection.
• A limit can be programmed on the output signal.

Mounting / installation

• Mounted vertically or horizontally on a DIN rail. Using the 2-channel version up to 84 channels per meter can be mounted.
• The 6333A can be mounted in zone 2 and zone 22 / Class I, Division 2, Groups A, B, C, D.

Further information
Supplier Product Page link: https://www.prelectronics.com/products/temperature-transmitters/6300/2-wire-programmable-transmitter-6333a/
